Omnikey Cardman 3121 entry level smart card keyboard in BLACK

Key Benefits

• USB 2.0
• Secure PIN entry
• PC/SC Smart card reader
• CT-Api support
• Protocols: T=0, T=1, S=8, S=9, S=10
• CCID compatible
• Reading/writing ISO 781-compliant chipcards
• EMV 2000 Level 1 approved

Downloads:

• SmartBoard G83-6644

Layout (country or language):

Product dependant, see table "Models"

Housing colour:

Product dependant, see table "Models"

Key colour:

Product dependant, see table "Models"

Weight (product):

approx. 680 g

Total weight (with packaging):

approx. 840 g

Cable Length:

• approx. 1.80 m

Storage Temperature:

• -20°C to 60°C

Operating Temperature:

• 0°C to 50°C

Current Consumption:

• max. 100 mA

Warranty:

• 2 years

Interface:

• USB

Product approvals:

System requirements:

• USB connection

Dimensions (product):

• approx. 458 x 170 x 52 mm

Packaging dimensions:

• approx. 495 x 200 x 55 mm

Keyboard:

• Service life, standard key: > 10 million key operations
• Operation characteristics: Soft pressure point
• Inscription technology: Laser
• Inscription layout: Standard
• Number of Keys: Product dependant, see table "Models"

Smartcard-Reader:

• Hardware interface: USB
• Agency Approvals: EMV 2000 Level 1,
• Chip-card protocols : T=0, T=1, S=8, S=9, S=10,
• Contact: mechanical swipe reader,
• Software interface: CT-Api, PC/SC, CCID,
• Mating cycles: approx. 100,000 operations
• Compatible chip card types:
  • Reads and writes on all ISO 7816 cards
• Transmission speed reader <==> card: 412,903 Bit/s
• Transmission speed reader <==> system: max. 12 MBit/s
• Chip card pulse frequency: 4.8 MHz

Packaging Unit:

• Number of products in the master package: 53
• Number of master packages per pallet: 2
